Union manager
The Union manager command opens a small dashboard that shows the workpiece union hierarchy, as in the example below.
With the toggle markers the tree can be expanded or collapsed.
Each individual node in this hierarchy has an option to be visualized or not. The symbol in front of the workpiece node enables to switch the visualization on or off.
 |  | |
| Visualization on | Visualization off |
The node visualization should not be confused with the Show / Hide state of an object. In the last case the object is moved to the Show or Hide workspace. The node visualization does not do this. Within the union workpiece it enables to display each individual node of the union.
On each node the Pie menu can be opened to disassemble a child workpiece from its parent.
